PCBA  Images

About TECircuit

Found: TECircuit has been operating since 2004.

Location: An electronics manufacturing service(EMS) provider located in Shenzhen China.

Item: Customizable EMS PCB, offers a full range of one-stop shop services.

Service: Printed Circuit Board (PCB)and Printed Circuit Board Assembly(PCBA), Flexible Printed Circuit Board(FPC), Components Sourcing, Box-Building, Testing.

Quality Assurance: UL,ISO 9001, ISO 14001, ISO 13485, ITAF 16949 andcomplied with ROHS and REACH.

Factory Pictures:
Company's own plant : 50,000 sqm; Employees : 930+; Monthly production capacity : 100,000 m2

PCBA  Applications

• Home Entertainment and Social Gaming: The PCBA enables automatic scoring for various games (e.g., 301, Cricket), voice feedback, and player profile management, facilitating immediate and engaging gameplay for friends and family.

• Commercial and Hospitality Operations: Deployed in bars and arcades, the PCBA supports coin-operated or credit-based systems, tracks statistics for leagues, and manages high-traffic usage, serving as a reliable revenue-generating entertainment hub.

• Competitive Training and Skill Development: The PCBA provides detailed analytics on scoring consistency and accuracy per segment, allowing amateur and professional players to analyze performance and refine their technique through data-driven practice.

• Organized League and Tournament Management: The system facilitates digital leagues by tracking player rankings, match histories, and averages across multiple venues, streamlining the administration of formal competitions.

• Solo Challenge and Adaptive Play: Offers solo practice modes and computer opponents of varying difficulty, allowing for individual goal-oriented play and making the game accessible with adjustable parameters and safer soft-tip darts.

PCBA Features

1. High-Density Segment Sensing Matrix: The PCBA integrates a sophisticated grid of pressure-sensitive or capacitive touch sensors that precisely detect the impact location to identify the exact segment (single, double, triple, bullseye) struck by each dart.

2. High-Speed Microcontroller Unit (MCU): Utilizes a dedicated MCU to process input from hundreds of sensor points in real-time, calculate complex scores, manage game logic, and drive display and audio systems without perceptible delay.

3. Multi-Player LED Scoring Display Driver: Includes driver circuitry for bright LED displays or matrix panels that clearly show individual player scores, remaining points, and game status to all participants.

4. Synthetic Voice and Audio Feedback System: Features an audio processor and amplifier to generate clear voice announcements of scores and game events, enhancing the interactive atmosphere.

5. Multi-Mode Connectivity (Wi-Fi, Bluetooth): The board integrates Wi-Fi for online updates and leaderboard access, and Bluetooth for connecting to companion smartphone apps for advanced statistics and profile management.

6. Robust Input/Output for Game Controls: Designed with interfaces for physical menu buttons and often an audio jack, providing comprehensive control over the gaming experience.

7. Advanced Power Management IC (PMIC): Employs a PMIC to handle varying power demands from the sensor matrix, display, and audio system, ensuring stable operation and supporting efficient power use in both plugged-in and portable scenarios.

FAQ

​PCB & PCBA  Description​

PCB Assembly OEM Service

Electronic Components Material Purchasing

Bare PCB Fabrication

Cable, Wire-harness Assembly, Sheet Metal, Electrical Cabinet Assembly Service

PCB Assembly Service: SMT, BGA, DIP

PCBA test: AOI, In-Circuit Test (ICT), Functioal Test (FCT)

Conformal Coating Service

Prototyping and Mass Production

​​

PCBA ODM service

PCB Layout, PCBA Design According To Your Idea

PCBA Copy/Clone

Digital Circuit Design / Analog Circuit Design/ lRF Design /Embedded Software Design

Firmware and Microcode Programming Windows Application (GUI) Programming/Windows Device Driver (WDM) Programming

Embedded User Interface Design / lSystem Hardware Design

​
